Palo Alto Networks Strata
Secure the Enterprise

Palo Alto Networks Strata

Prevent attacks with the industry-leading network security suite, which enables organizations to embrace network transformation while consistently securing users, applications, and data, no matter where they reside.

Next Generation Firewall

Securing your enterprise starts with your firewall. It’s time to move from legacy security to prevention-based architectures that evolve with your business. Our industry-leading next-generation family of firewalls have been redefining network security for 15 years, and counting.

PA-220 Firewall

PA-220 Firewall Appliance

  • 500 Mbps firewall throughput (App-ID enabled)
  • 150 Mbps threat prevention throughput
  • 100 Mbps IPSec VPN throughput
  • 64,000 max sessions
  • 4,200 new sessions per second
  • 250 IPSec VPN tunnels/tunnel interfaces
  • 3 virtual routers
  • 15 security zones
  • 250 max number of policies

PA-220R Firewall

PA-220 Firewall Appliance

  • 500 Mbps firewall throughput1
  • 150 Mbps Threat Prevention throughput2
  • 100 Mbps IPsec VPN throughput
  • 64,000 max sessions
  • 4,200 new sessions per second3
  • 1,000 IPsec VPN tunnels/tunnel interfaces
  • 3 virtual routers
  • 15 security zones
  • 250 max number of policies

PA-820 Firewall

Palo Alto Networks Enterprise Firewall PA-820

  • 940 Mbps firewall throughput (App-ID enabled)
  • 610 Mbps threat prevention throughput
  • 400 Mbps IPSec VPN throughput
  • 128,000 max sessions
  • 8,300 new sessions per second
  • 1000 IPSec VPN tunnels/tunnel interfaces
  • 5 virtual routers
  • 30 security zones
  • 1,500 max number of policies

PA-850 Firewall

Palo Alto Networks Enterprise Firewall PA-850

  • 1.9 Gbps firewall throughput (App-ID enabled)
  • 780 Mbps threat prevention throughput
  • 400 Mbps IPSec VPN throughput
  • 192,000 max sessions
  • 9,500 new sessions per second
  • 1000 IPSec VPN tunnels/tunnel interfaces
  • 5 virtual routers
  • 40 security zones
  • 1,500 max number of policies


PA-3220 Firewall

PA-3220 Firewall Appliance

  • 5 Gbps firewall throughput (App-ID enabled1)
  • 2.2 Gbps Threat Prevention throughput2
  • 2.5 Gbps IPsec VPN throughput
  • 1,000,000 sessions
  • 58,000 new sessions per second3
  • 4,000 IPsec VPN tunnels/tunnel interfaces
  • 1,024 SSL VPN Users
  • 10 virtual routers
  • 1/6 virtual systems (base/max4)
  • 60 security zones
  • 2,500 max number of policies

PA-3250 Firewall

PA-3250 Firewall Appliance

  • 6.3 Gbps firewall throughput
    (App-ID enabled1)
  • 3 Gbps Threat Prevention throughput2
  • 3.2 Gbps IPsec VPN throughput
  • 2,000,000 sessions
  • 94,000 new sessions per second3
  • 6,000 IPsec VPN tunnels/tunnel interfaces
  • 2,048 SSL VPN Users
  • 10 virtual routers
  • 1/6 virtual systems (base/max4)
  • 60 security zones
  • 5,000 max number of policies

PA-3260 Firewall

PA-3260 Firewall Appliance

  • 8.8 Gbps firewall throughput1
    (App-ID enabled1)
  • 4.7 Gbps Threat Prevention throughput2
  • 4.8 Gbps IPsec VPN throughput
  • 3,000,000 max sessions
  • 135,000 new sessions per second3
  • 6,000 IPsec VPN tunnels/tunnel interfaces
  • 2,048 SSL VPN Users
  • 10 virtual routers
  • 1/6 virtual systems (base/max4)
  • 60 security zones
  • 5,000 max number of policies

PA-5220 Firewall

PA-5220 Firewall

  • 18.5 Gbps firewall throughput (App-ID enabled)
  • 9.2 Gbps threat prevention throughput
  • 5 Gbps IPSec VPN throughput
  • 4,000,000 max sessions
  • 169,000 new sessions per second
  • 20 virtual routers
  • 10/20 virtual systems (base/max)


PA-5250 Firewall

PA-5250 Firewall

  • 35.9 Gbps firewall throughput (App-ID enabled)
  • 20.4 Gbps threat prevention throughput
  • 14 Gbps IPSec VPN throughput
  • 8,000,000 max sessions
  • 348,000 new sessions per second
  • 125 virtual routers
  • 25/125 virtual systems (base/max)



PA-3410 Firewall

PA-3410 Firewall

  • 14.5/11.6 Gbps firewall throughput (HTTP/appmix)
  • 5.2/5.9 Gbps threat prevention throughput (HTTP/appmix)
  • 6.8 Gbps IPSec VPN throughput
  • 1.4 M max sessions
  • 145,000 new sessions per second
  • 1/11 virtual systems (base/max)

PA-3420 Firewall

PA-3420 Firewall

  • 20.8/16.9 Gbps firewall throughput (HTTP/appmix)
  • 7.6/8.7 Gbps Gbps threat prevention throughput (HTTP/appmix)
  • 9.9 Gbps IPSec VPN throughput
  • 2 M max sessions
  • 205,000 new sessions per second
  • 1/11 virtual systems (base/max)

PA-3430 Firewall

PA-3430 Firewall

  • 25.5/20.5 Gbps firewall throughput (HTTP/appmix)
  • 9.2/10.5 Gbps 7.6 threat prevention throughput (HTTP/appmix)
  • 12.2 Gbps IPSec VPN throughput
  • 2.5 M max sessions
  • 240,000 new sessions per second
  • 1/11 virtual systems (base/max)


PA-5260 Firewall

PA-5260 Firewall

  • 72.3 Gbps firewall throughput (App-ID enabled)
  • 30.2 Gbps threat prevention throughput
  • 21 Gbps IPSec VPN throughput
  • 32,000,000 max sessions
  • 458,000 new sessions per second
  • 225 virtual routers
  • 25/225 virtual systems (base/max)


PA-5280 Firewall

PA-5260 Firewall

  • 68 Gbps firewall throughput (App-ID enabled1)
  • 30 Gbps Threat Prevention throughput2
  • 24 Gbps IPsec VPN throughput
  • 64,000,000 max sessions
  • 462,000 new sessions per second3
  • 225 virtual routers
  • 25/225 virtual systems (base/max4)


PA-5450 Firewall

PA-5450 Firewall



  • 200 Gbps firewall throughput (HTTP/appmix)
  • 125 Gbps Threat Prevention throughput
  • 95 Gbps IPsec VPN throughput
  • 100M Max sessions
  • 4M New sessions per second



PA-5410 Firewall

PA-5410 Firewall

  • 45.2/36.7 Gbps firewall throughput (HTTP/appmix)
  • 22/23.5 Gbps threat prevention throughput (HTTP/appmix)
  • 21 Gbps IPSec VPN throughput
  • 4.1 M max sessions
  • 246,000new sessions per second
  • 10/20 virtual systems (base/max)

PA-5420 Firewall

PA-5420 Firewall

  • 53.7/47.5 Gbps firewall throughput (HTTP/appmix)
  • 28.8/30.5 Gbps Gbps threat prevention throughput (HTTP/appmix)
  • 28.7 Gbps IPSec VPN throughput
  • 6.2 M max sessions
  • 315,000 new sessions per second
  • 15/65 virtual systems (base/max)

PA-5430 Firewall

PA-5430 Firewall

  • 63/59.4 Gbps firewall throughput (HTTP/appmix)
  • 37.6/40.9 Gbps threat prevention throughput (HTTP/appmix)
  • 42 Gbps IPSec VPN throughput
  • 8.3M max sessions
  • 366,000 new sessions per second
  • 25/125 virtual systems (base/max)


PA-7050 Firewall

PA-7050 Firewall

  • 120 Gbps firewall throughput (App-ID enabled)
  • 60 Gbps threat prevention throughput
  • 24 Gbps IPSec VPN throughput
  • 24,000,000 max sessions
  • 720,000 new sessions per second
  • 120,000 IPSec VPN tunnels/tunnel interfaces
  • 20,000 SSL VPN Users
  • 225 virtual routers
  • 25/225 virtual systems (base/max)
  • 900 security zones
  • 40,000 max number of policies

PA-7080 Firewall

PA-7080 Firewall

  • 200 Gbps firewall throughput (App-ID enabled)
  • 100 Gbps threat prevention throughput
  • 80 Gbps IPSec VPN throughput
  • 1,200,000 max sessions
  • 80,000,000 new sessions per second
  • 225 virtual routers
  • 25/225 virtual systems (base/max)
  • 900 security zones

Cloud Delivered Networking and Security

Our comprehensive range of security subscriptions extend your security policies with threat protection that is constantly kept up to date.

CN Series Firewall

VM-SERIES-VIRTUAL-NGFWS

Cloud NGFW

Panorama

Security deployments can overload IT teams with complex security rules and data from multiple sources. Panorama offers easy-to-implement and centralized management features to gain insight into network-wide traffic and threats, and administer your firewalls everywhere.
